Ultrafiltration working principle| Advantage & Disadvantage


Ultrafiltration Definition:

Ultrafiltration (UF) is a pressure-driven filtration system that uses industrial & home water filtration. It was eliminate suspended solids, Algae, Bacteria and other pathogens to produce clean water.

The ultrafiltration membrane pore size around 0.01 micron that means water particle passes through below 0.01-micron size. It would eliminate all these larger particles and may get rid of some viruses.

Ultrafiltration Working Principle:

The UF makes hollow fibres membrane material, and water flows inside the shell. Suspended solids and large pore sizes are held in the membrane surface & clean water passes through the membrane. Ultrafiltration is the same category filtration system as reverse osmosis, nanofiltration & microfiltration system. The only difference is the size of particle hold during filtration.

UF is best for removal of suspended solids, colloids, bacteria, and algae respect to other filtration systems.

Ultrafiltration Process:

It is a pressure-driven water filtration process. In this filtration process, membrane pore size plays a vital role. The water passes to filter through the pump. We need 2.0 to 2.5 kg/cm2 water pressure to processes the filtration. Blocked contaminant the UF membrane surface & clean water passes through the membrane. This filter needs backwash every 20 – 30 minute in operation and chemical cleaning after complication ten cycle of backwash. This filtration system is run through automation or semi-automation.


Ultrafiltration System used:

  • Drinking water treatment
  • RO plant pretreatment
  • Wastewater treatment
  • Cooling water treatment


Ultrafiltration system is an eco-friendly water filtration system. It has a recovery rate of more than 95%. This water filtration widely uses in-home water filtration & industrial water filtration system.

  1. A minimal amount of water wastage during this filtration process.
  2. ECO-friendly filtration system.
  3. 99 % of bacteria and viruses removed.
  4. Does not remove essential minerals in the water.
  5. Easy handle & run automation.
  6. Low maintenance cost.
  7. The system operates at low pressure.


  • Does not remove dissolved inorganics.
  • Does not remove dissolved solids.

What does ultrafiltration remove?

UF has removed the particle size 4000 times smaller with respect to human hair. It eliminates more than 95% of water contaminant.

  • Suspended solid particle
  • Turbidity
  • Bacteria & algae
  • Silica
  • Silt

Are you know about water?

Every life can not live without water, but maximum people’s don’t know much more about water. This is the real fact. The popular article “What is Water?” gives you all answer about water.
